2 SIP lines, SIP hotspot
2.3” Dot-matrix display
HD audio on speakerphone and handset
Support local 6-way audio conference
Dual Fast ports, integrated PoE (only X3SP Lite)
Simplicity and Ease of Use
By inheriting the aesthetic design of Fanvil’s previous generation IP phones, the X3S Lite/X3SP Lite’s appearance is elegant, simple and stylish. The Intuitive and user-friendly UI, make navigation easy and requires minimal training.
HD Audio Call with Excellent Noise Reduction
The X3S Lite/X3SP Lite supports full HD audio effect, by built-in HD audio handset, HD speakers, and using wideband audio codec protocol G.722 and Opus. Efficient ANS (Automatic Noise Suppression) technology can reduce the background noise in different environment, and provide you comfortable communication experience.
Support 6-way Audio Conference
The X3S Lite/X3SP Lite supports 6-way audio conference, the conference organizer can invite up to 5 participants to join in the conference, making the collaboration between different departments or organizations easier and more efficient.
High Scalability with DSS Keys
Line keys can also be adjusted as DSS keys according to the requirements of the configuration to achieve application functions. Each DSS key can be set to LINE /BLF/ speed dial extension which can be triggered by one click after configuring the change function
Flexible Office Collaboration
The X3S Lite/ X3SP Lite supports connecting the EHS wireless earphone through the EHS adapter so you can multitask while making an audio call, that will greatly improve your work efficiency.
| Basic general data | |
| Manufacturer | Fanvil |
| Model | X3SP Lite |
| Type | VoIP phone |
| Physical specification | |
| Main display | 2.3" black and white screen with backlight |
| Keyboard | 34 keys, including: 4 Soft-keys 7 Function keys (Hold/Transfer/Conference/Phonebook /MWI/Headset/Dial) 2 Line keys (with LED) 4 navigation keys 1 OK button 12 standard telephone number keys 3 volume control buttons (Up/Down/Mute (Microphone)) 1 hands-free car kit button |
| Handset | 1 x HD (RJ9) |
| Earphone cable | 1 x standard RJ9 handset cable |
| Ethernet cable | 1 x 1.5M CAT5 |
| Rear rack | Yes |
| Status indicator | 1 x (red) |
| RJ45 port | 1 x network 1 x computer (connected to network) |
| Hole for security key | Yes |
| Power input | DC 5V/0.6A |
| Energy consumption | Idle 0.9~1.65W Peak 1.8~2.95W |
| Operating temperature | 0~45℃ |
| Operating humidity | 10~95% |
| Installation | Desktop Stand Wall mounted (additional wall hanging parts needed) |
| Colour | Black |
| Device dimensions | Desk stand (angle 1): 169 x 186.3 x 174.5 mm Desk Stand (Angle 2): 169 x 177.6 x 183.7 mm Wall mount: 169 x 115.6 x 212.5 mm |
| Phone features | |
| Local phonebook (1000 entries) Remote phonebook (XML/LDAP, 1000 entries) Call logs (incoming/outgoing/missed, 600 entries) Call filtering black/white list Screen saver Voice message waiting indication (VMWI) Programmable DSS/soft keys Network time synchronisation Plantronics wireless headset support (via Plantronics APD-80 EHS Cable) APD-80 EHS Cable) Jabra wireless headset support (via Fanvil EHS20 EHS Cable) Recording support (via server) Action URL / Active URI uaCSTA |
|
| Call functions | |
| Call / Accept / reject Mute / Unmute (microphone) Hold / Resume call Call waiting Intercom Caller ID display Speed dial Anonymous call (Hide caller ID) Call transfer (Always/Interests/No answer) Call transfer (attended/unattended) Call parking/reception (server dependent) Redial Do Not Disturb (Do-Not-Disturb) Automatic call answering Voice messaging (server dependent) 3-way conference Hotline Hot-desking |
|
| Audio | |
| HD Voice microphone/speaker (handset/speaker, frequency response 0 ~ 7KHz) HAC headphone Wideband ADC/DAC 16KHz sampling Narrowband codec: G.711a/u, G.726-32K, G.729A/B, iLBC, G723.1 (optional) Broadband codec: G.722, Opus Full duplex acoustic echo cancellation (AEC) Voice Activity Detection (VAD) / Comfort Noise Generation (CNG) / Background Noise Estimation (BNE) / Noise Reduction (NR) / Automatic Gain Control (AGC) Packet Loss Concealment (PLC) Dynamic jitter adaptive buffer DTMF: in-band, out-of-band - DTMF-Relay (RFC2833) / SIP INFO |
|
| Network connectivity | |
| Physical: 10/100 Mbps Fast Ethernet, dual bridged port for PC bypass IP Mode:IPv4/IPv6/IPv4 |
|
| Protocols | |
| SIP2.0 over UDP/TCP/TLS RTP/RTCP/SRTP STUN DHCP IPv6 LLDP PPPoE 802.1x L2TP OpenVPN SNTP FTP/TFTP HTTP/HTTPS TR-069 AES128 |
|
| Implementation and management | |
| Auto-Provisioning via FTP/TFTP/HTTP/HTTPS/DHCP OPT66/SIP/ PNP/TR-069 Web-based management portal Internet Packet Dump Export/import of configuration Phonebook Import/Export Firmware Upgrade Syslog |
|
