CABLE CONSTRUCTION | |
---|---|
CONDUCTOR | |
Material | Bare Copper |
Wire Size | 26AWG |
INSULATION | |
Material | HDPE |
Thickness | 0.18 |
Diameter | 0.97±0.05mm |
Colors | Blue/White-Blue |
JACKET | |
Material | PVC, flame retardant CM grade |
Thickness | Nom. 0.59 |
Diameter | 5.5 ±0.2mm |
Color | Blue |
Maximum Tensile Strength | 1.05 kgf/mm2 |
RJ45 PLUG | |
Plug Type | Un-shielded RJ45 plug | Housing>polycarbonate |
Contact Material | Copper alloy 50u” gold plated over nickel |
Strength | 20lbs. min |
Durability | 750 cycles min. |
Wiring schemes | T568B (Standard) – T568A on request |
ELECTRICAL | |
Impedance | 93.8Ω ± 15 Ω at 20℃ |
Capacitance unbalance pair to ground | max. 330pf/100m Max |
D.C.R (Max.) | nom. 14.8 ohm/100m at 20℃ |
DC Insulation Resistance | 500MΩ/100m min. |
Resistance unbalance | 3% MAX./100m |
